Reference

Information

Specifications

NOTE:

*Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.

Video

Maximum data rate ........................ 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ...................... 225 MHz
Resolution range ............................ Up to 1920x1200 or 1080p @ 60 Hz
Formats .......................................... RGB and YCbCr digital video
Standards ....................................... DVI 1.0, HDMI 1.3
Impedance ..................................... 100 ohms
Input video signal ........................... 1.2 Vp-p (TMDS)
ID bits ............................................ 5 Vp-p (TTL)

Video input

Number/signal type ........................ 1 single link HDMI (or DVI-D*)
Connectors .................................... 1 female HDMI type A
Equalization ................................... Automatic for up to -40 dB of cable loss
Input cable length .......................... Up to 150' (46 m) at 1080p / 12 bit @ 60 Hz

Up to 175' (53 m) at 1080p / 10 bit @ 60 Hz
Up to 200' (61 m) at 1920x1200, 1600x1200, or 1080p / 8 bit @ 60 Hz
Up to 250' (76 m) at 720p, 1080i, 1024x768, or 1280x1024 @ 60 Hz
Longer distances are possible with lower rates and/or high quality cable.

NOTE:

The transmission distance varies greatly depending on the signal resolution and on the type of cable,

source, and display used in the system.

Video output

Number/signal type ........................ 1 single link HDMI (or DVI-D*)
Connectors .................................... 1 female HDMI type A
Output cable length ....................... Up to 15' (5 m)

General

Power ............................................ Supplied by an external power supply or by the 5 V signal from an HDMI source

(pin 18) or a DVI source (pin 14)

External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements .............. 12 VDC, 0.2 A from an external power supply or

5 VDC, 0.05 A from an HDMI or DVI source

Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling .......................................... Convection, no vents

HDMI 101 Plus • Reference Information

7
