Control/remote
Serial control ports on each unit (transmitter and receiver)
Control .................................... 1 RS-232, 3.5 mm captive screw connector, 5 pole (3 pins are used) (rear panel);
in parallel with front panel jack
1 RS-232, 2.5 mm mini stereo jack (front panel)
Pass-through ............................ 1 RS-232, 3.5 mm captive screw connector, 5 pole (3 pins are used) (rear panel)
Baud rate and protocol
Control .................................... 9600 baud, 8 data bits, 1 stop bit, no parity
Pass-through ............................ 9600 to 115200 baud
Serial control pin configurations
Pass-through ............................ Captive screw connector: 1 = Tx, 2 = Rx, 3 = GND
Control .................................... Captive screw connector: 3 = GND, 4 = Tx, 5 = Rx
Mini stereo jack: tip = Tx, ring = Rx, sleeve = GND
Program control ............................. Extron's control/configuration program for Windows®
Extron's Simple Instruction Set (SIS™)
General
External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements .............. 12 VDC, 0.6 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on left side and top
Mounting
Rack mount ............................. Yes, with optional rack shelf kit
Furniture mount ...................... Yes, with optional under-desk mounting kit
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 4.3" W x 6.0" D (1U high, quarter rack wide)
(4.3 cm H x 10.9 cm W x 15.2 cm D)
(Depth excludes connectors.)
Product weight ............................... 0.8 lbs (0.4 kg) per unit, 1.6 lbs (0.7 kg) per pair
Shipping weight ............................. 3 lbs (2 kg) per unit, 6 lbs (3 kg) per pair
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, CUL, FDA Class 1, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES: All nominal levels are at ±10%.
Specifications are subject to change without notice.
FOX Tx/Rx AV • Specifications 26
