Conventions Used in this Guide
Notifications
In this user guide, the following are used:
CAUTION: A caution indicates a potential hazard to equipment or data.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.
WARNING: A warning warns of things or actions that might cause injury, death, or
other severe consequences.
Ground Symbols
NOTE: Control signal ground pins may be labeled as or “G.” Audio ground pins may
be labeled as or .
The wiring and function are the same, whichever way your product is labeled.
Copyright
© 2012 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
