Audio
Gain
Default .................................... Unbalanced: -6 dB
Balanced: 0 dB
Frequency response ................. 20 Hz to 20 kHz, ±0.5 dB
THD + Noise ............................ 0.10% @ 1 kHz at nominal level
S/N .......................................... >80 dB at maximum output (unweighted)
Audio bits per sample .............. 18 bits per channel, 2 channels (L, R)
Sampling rate .......................... 48 kHz
Audio input — See the transmitter specifications
Audio output
Number/signal type ........................ 8 balanced/unbalanced stereo or 16 balanced/unbalanced mono
Connectors .................................... (8) 3.5 mm captive screw connectors, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... >+11 dBu, balanced at 1% THD+N
Audio Delay ................................... 1.5 frames
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
General
Power ............................................ Internal
Input: 100-240 VAC, 50-60 Hz
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on top and side panels
Thermal dissipation
240 VAC, 50 Hz ....................... 47.2 BTU/hr
Mounting
Rack mount ............................. Yes, with optional rack shelf
Furniture mount ...................... Yes, with optional under desk mounting kit
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 8.7" W x 6.0" D (1U high, half rack wide)
(4.3 cm H x 22.1 cm W x 15.2 cm D)
(Depth excludes connectors.)
Product weight ............................... 2.3 lbs (1.0 kg)
Shipping weight ............................. 4 lbs (2 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, FDA Class 1, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: • All nominal levels are at ±10%.
• Specifications are subject to change without notice.
8.0-033012-D3
FOX AEX 108 • Reference Information 10
