B-3

DVS 100 and DVS 150 Reference Information

Pre-cut cables

BNC-4 HR cable is used for RGBS cable runs, and BNC-5 is used for
RGBHV cable runs. Either type can also be used for RGsB (sync on
green). All Extron BNC cables have male gender connectors at both
ends. A plenum version of the BNC-5 HR cable is also available.

BNC-4 HR Cable

BNC-4-25’ HR (25 feet/7.5 meters)

26-210-04

BNC-4-50’ HR (50 feet/15.0 meters)

26-210-05

BNC-4-75’ HR (75 feet/23.0 meters)

26-210-06

BNC-4-100’ HR (100 feet/30.0 meters)

26-210-07

BNC-4-150’ HR (150 feet/45.0 meters)

26-210-08

BNC-4-200’ HR (200 feet/60.0 meters)

26-210-09

BNC-4-250’ HR (250 feet/75.0 meters)

26-210-54

BNC-4-300’ HR (300 feet/90.0 meters)

26-210-53

BNC-5 HR Cable

BNC-5-25’ HR (25 feet/7.5 meters)

26-260-03

BNC-5-50’ HR (50 feet/15.0 meters)

26-260-04

BNC-5-75’ HR (75 feet/23.0 meters)

26-260-16

BNC-5-100’ HR (100 feet/30.0 meters)

26-260-05

BNC-5-150’ HR (150 feet/45.0 meters)

26-260-12

BNC-5-200’ HR (200 feet/60.0 meters)

26-260-06

BNC-5-250’ HR (250 feet/75.0 meters)

26-260-18

BNC-5-300’ HR (300 feet/90.0 meters)

26-260-14

Bulk cable in lengths up to 5000’ rolls is available with or without

connectors.

Glossary

Autoswitch mode —

Automatically selects the active input device. If

more than one input device is on, the device with the highest
video quality is selected.

Blanking, top and bottom —

A feature that removes noise and

unwanted information, such as tape head switching and closed
captioning, from the top and bottom portions of the screen.

Channel reset —

Reconfigures the settings for the active input to the

original factory settings.

Detail filter —

Controls the sampling of the horizontal plane, thereby

affecting the sharpness or smoothness of the scaled image.

Digital video scaler —

See scaler.

Executive mode —

Locks out all front panel functions except input

selection.

Freeze —

Locks the output display to the current image.

Motion compensation —

Eliminates scan lines and “jaggies” in motion

video.

Precise image processing —

A combination of three technologies

(motion compensation, three-line adaptive comb filter, and quad
standard decoder) that produces the best possible upscaled image.

Quad standard decoder —

A device, compatible with the NTSC 3.58,

NTSC 4.43, SECAM, and PAL standards, that separates the RGBS
(red, green, blue, and sync) signals from a composite, S-video, or
component video signal.
