Installation, cont’d

DVS 100 and DVS 150 Installation

2-8

Vertical sync polarity (V-SYNC) —

Changes the polarity of the vertical

sync signal to allow any projector to distinguish the DVS 100 input
from a standard RGB input. To toggle between Positive and
Negative, turn the adjustment knob while the Vertical sync menu
is displayed. By default, the vertical sync polarity is set to
Negative.

Sync on green (SOG) —

If set to Yes, provides sync on green (RGsB or

SOG) output. If set to No, provides RGBS or RGBHV output,
depending on the attached cables. To toggle between Yes and No,
turn the adjustment knob while the Sync on green menu is
displayed. By default, Sync on green is set to No.

Still (STILL) —

If set to On, provides enhanced resolution for easier

viewing of text and other motionless video. If set to Off, provides
optimized motion video. To toggle between On and Off, turn the
adjustment knob while the Still menu is displayed. By default,
still mode is set to Off.

Detail (DETAIL) —

Applies a filter to improve the image’s level of

detail. To switch between 1 (low), 2 (medium), and 3 (high), turn
the adjustment knob while the Detail menu is displayed. By
default, detail mode is set to 3.
