DTP T USW 233 • Reference Information
18
Reference
Information
This section provides procedures for mounting the DTP T USW 233 switching transmitter
and disconnecting the ground between it and a compatible receiver.
•
•
Mounting the Switcher
ATTENTION:
•
Installation and service must be performed by authorized personnel only.
•
Avoid ground potential differences between the switching transmitter and receiver
installation sites, which can lead to
equipment damage or a missing or unstable
picture. If a potential difference cannot be avoided, remove the ground connection
between the units and locally power both units (see
on the next page).
The 1-inch high, half rack width DTP T USW 233 switching transmitter can be placed on a
table, mounted in a rack, or mounted under a desk or table.
Tabletop Use
Affix the included rubber feet to the bottom of the unit and place it in any convenient
location.
Mounting kits
Mount the unit using any optional compatible mounting kit listed on the Extron website
(
www.extron.com
), in accordance with the directions included with the kit. For rack
