DTP T USW 233 • Remote Control
12
Remote Control
This section includes:
•
•
Simple Instruction Set Control
The DTP T USW 233 switcher can be remotely controlled via its rear panel Remote RS-232
port, its front panel configuration (USB) port, and its rear panel Remote Contact port.
Remote control devices can be:
•
A host device such as a computer or control system and the Extron Simple Instruction
Set
•
A contact closure device such as an Extron KP 6 Keypad Control or a Show Me video
cable
Contact Closure Control
The rear panel Remote Contact port (see
on page 4) provides a way to select
an input to the switcher using a remote contact closure device. The contact closure pin
assignments are shown on page 4.
NOTE: The switcher must be in normal (manual) mode.
To select a different input number using a contact closure device, momentarily short the pin
for the desired input number to ground. To force one of the inputs to be always selected,
leave the short to ground in place. The short overrides front panel input selections.
