DTP T USW 233 • Remote Control 16
Command Function SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
EDID Minder
NOTE: See table 1, below for the EDID values.
Assign EDID to an input E
A
X!
*
X&
EDID
}
EdidA
X!
*
X&] Defaults: 03 and 50.
Save the EDID of the connected
display to a user location E
S
X*
EDID
}
EdidS
X*] Save EDID of display connected to the
output to the user store slot 66, 67, or 68.
View the EDID assignment E
A
X!
EDID
} X&]
View raw EDID data E
R
X!
EDID
} X(] Read data as text from the EDID
assigned and used on input
X!
.
View EDID native resolution E
N
X!
EDID
} X1)] Read out native resolution and refresh
rate from the EDID assigned to the
specified input in plain text.
Example:
1920x1200 @60Hz
Table 1. EDID Values
X& Value X& Value X& Value X& Value
VGA – PC values
01 800x600 @ 60 Hz 05 1280x800 @ 60 Hz 09 1400x1050 @ 60 Hz 13 1680x1050 @ 60 Hz
02 1024x768 @ 60 Hz 06 1280x1024 @ 60 Hz 10 1440x900 @ 60 Hz 14 1920x1080 @ 60 Hz
03* 1280x720 @ 60 Hz 07 1360x768 @ 60 Hz 11 1600x900 @ 60 Hz 15 1920x1200 @ 60 Hz
04 1280x768 @ 60 Hz 08 1366x768 @ 60 Hz 12 1600x1200 @ 60 Hz 16 2048x1080 @ 60 Hz
DVI – PC values
17 800x600 @ 60 Hz 21 1280x800 @ 60 Hz 25 1400x1050 @ 60 Hz 29 1680x1050 @ 60 Hz
18 1024x768 @ 60 Hz 22 1280x1024 @ 60 Hz 26 1440x900 @ 60 Hz 30 1920x1080 @ 60 Hz
19 1280x720 @ 60 Hz 23 1360x768 @ 60 Hz 27 1600x900 @ 60 Hz 31 1920x1200 @ 60 Hz
20 1280x768 @ 60 Hz 24 1366x768 @ 60 Hz 28 16001200 @ 60 Hz 32 2048x1080 @ 60 Hz
HDMI – PC values, with 2-channel audio
33 800x600 @ 60 Hz 37 1280x1024 @ 60 Hz 41 1440x900 @ 60 Hz 45 1920x1200 @ 60 Hz
34 1024x768 @ 60 Hz 38 1360x768 @ 60 Hz 42 1600x900 @ 60 Hz 46 2048x1080 @ 60 Hz
35 1280x768 @ 60 Hz 39 1366x768 @ 60 Hz 43 1600x1200 @ 60 Hz
36 1280x800 @ 60 Hz 40 1400x1050 @ 60 Hz 44 1680x1050 @ 60 Hz
HDMI – HDTV values, with 2-channel audio
47 480p @ 60 Hz 50 ✝ 720p @ 60 Hz 53 1080p @ 50/25 Hz 56 1080p @ 60 Hz
48 576p @ 50 Hz 51 1080i @ 50 Hz 54 1080p @ 50 Hz
49 720p @ 50 Hz 52 1080i @ 60 Hz 55 1080p @ 60/24 Hz
HDMI – HDTV values, with multi-channel audio
57 720p @ 50 Hz 59 1080i @ 50 Hz 61 1080p @ 50/25 Hz 63 1080p @ 60/24 Hz
58 720p @ 60 Hz 60 1080i @ 60 Hz 62 1080p @ 50 Hz 64 1080p @ 60 Hz
Output and user locations
X& Source X& Source X& Source X& Source
65 Output 66 User location 1 67 User location 2 68 User location 3
* Default for input 1.
✝
Default for inputs 2 and 3.
NOTE: X! = Input number 1 through 3
X& = EDID See table 1, above.
X* = User EDID location 66 , 67 , or 68
X( = Raw EDID data 128 or 256 bytes of hexadecimal data
X1) = Resolution and rate in plain text Example: 1920x1200 • @60Hz
