CAT 5 Receivers • Introduction CAT 5 Receivers • Introduction
Introduction, cont’d Introduction
The Extron CAT 5 receivers receive long-distance transmissions
of RGB video, component video, S-video, composite video, and
stereo audio over shielded twisted pair (STP) or unshielded
twisted pair (UTP) cable.
The minimum reliable transmission distance is 50 feet. The
maximum distance is determined by the output frequency and
resolution. The following table specifies the recommended
maximum transmission distances using Belden Media Twist
1872A 350 MHz cable or equivalent terminated with Category 6,
or at least Category 5e, rated connectors.
Extron recommends using the highest quality cable
available and affordable. We also recommend the use of
pre-terminated and tested cables. Cables terminated on
site should be tested before use to ensure that they
comply with Category 5e specifications.
Recommended transmission ranges at 60 Hz
Video format Maximum range
Composite video and audio 1000 feet
Component video and S-video 1000 feet
640 x 480 1000 feet
800 x 600 800 feet
1024 x 768 600 feet
1280 x 1024 400 feet
1600 x 1280 200 feet
It is possible to exceed the recommended distances,
however, image quality may be reduced.
The CAT 5 receivers can only receive and output signals
transmitted by Extron CAT 5 transmitters. This user’s manual
documents the installation, features, and operation of the CAT 5
receivers only. For information about the CAT 5 receivers, refer
to the CAT 5 Transmitter Family User’s Manual, which
accompanies the transmitters.
Features
All Extron CAT 5 receivers provide the following features:
Audio output — Provides unbalanced (left/right) audio on
RCA connectors, and balanced or unbalanced audio on
3.5 mm, 5-pole captive screw connectors.
Cable length compensation — Allows you to select whether to
compensate for long cable runs automatically or
manually.
Level control — If manual cable length compensation is
selected, allows you to control the image brightness.
1-2
Peaking control — If manual cable length compensation is
selected, allows you to control the image sharpness.
CAT 5 R BNC A
The CAT 5 R BNC A receiver has the following features:
Video output — Provides RGBHV, RGBS, RGsB, or RGB video
on 5 BNC connectors.
RJ-45 connector — Allows attachment to an Extron CAT 5 TX
transmitter.
Mounting —
Mounts in a rack with Extron’s 1U rack shelf
(part #60-190-01).
Mounts in a rack with Extron’s Projector Mounting Kit
(part #70-077-04).
Mounts under or through furniture with Extron’s Under
Desk Mounting Kit (part #70-077-01) or Through Desk
Mounting Kit (part #70-077-02).
CAT 5 R BNC AV
The CAT 5 R BNC AV receiver has the following features:
Video output — Provides RGBHV, RGBS, RGsB, or RGB video
on 5 BNC connectors, and composite video on 1 BNC
connector.
RJ-45 connector — Allows attachment to an Extron CAT 5 TX
transmitter. One connector is for computer input, and
one is for A/V input.
Mounting —
Mounts in a rack with Extron’s 1U rack shelf
(part #60-190-01).
Mounts in a rack with Extron’s Projector Mounting Kit
(part #70-077-04).
Mounts under or through furniture with Extron’s Under
Desk Mounting Kit (part #70-077-01) or Through Desk
Mounting Kit (part #70-077-02).
CAT 5 R AV
The CAT 5 R AV receiver has the following features:
Video output — Provides composite video on one BNC
connector.
RJ-45 connector — Allows attachment to an Extron CAT 5 TX
transmitter.
1-3
