CAT 5 Receivers • Specifications, Accessories, and Part Numbers CAT 5 Receivers • Specifications, Accessories, and Part Numbers
Specifications, Accessories, and Part Numbers cont’d
A-5 A-4
Enclosure type .............................. Metal
Enclosure dimensions
CAT 5 R BNC A ............... 1.25” H x 8.7” W x 7.0” D
3.18 cm H x 22.10 cm W x 17.78 cm D
(Depth excludes connectors.)
CAT 5 R BNC AV ............ 1.68” H x 8.7” W x 7.0” D
4.27 cm H x 22.10 cm W x 17.78 cm D
(Depth excludes connectors.)
CAT 5 R AV ...................... 1.25” H x 4.75” W x 7.0” D
3.18 cm H x 12.07 cm W x 17.78 cm D
(Depth excludes connectors.)
Shipping weight ........................... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Approvals ..................................... UL, CUL, CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Specifications are subject to change without notice.
Included Parts
These items are included in each order for a specific CAT 5
receiver:
Included parts Part number
CAT 5 R BNC A 60-348-01
CAT 5 Receivers User’s Manual 68-547-01
CAT 5 Receivers label 33-603-04
External power supply, 15V, 0.8A 70-057-01
Captive screw connector, 5 pole, 3.5 mm 10-319-10
Captive screw connector, 3 pole, 3.5 mm 10-265-03
CAT 5 R BNC AV 60-345-01
CAT 5 Receivers User’s Guide 68-547-01
CAT 5 Receivers label 33-603-04
Captive screw connector, 5 pole, 3.5 mm 10-319-10
CAT 5 R AV 60-346-01
CAT 5 Receivers User’s Guide 68-547-01
CAT 5 Receivers label 33-603-04
External power supply, 15V, 0.8A 70-057-01
Captive screw connector, 5 pole, 3.5 mm 10-319-10
Captive screw connector, 3 pole, 3.5 mm 10-265-03
Accessories
Accessories Part number
Extron 19" 1U Universal Rack Shelf 60-190-01
Extron Under Desk Mounting Kit 70-077-01
Extron Thru-desk Mounting Kit 70-077-03
Extron Projector Mounting Kit 70-077-04
Cables/Adapters
Cable/adapter Part number
BNC-5-3’ MHR (3 feet/0.9 meters) 26-260-15
BNC-5-6’ MHR (6 feet/1.8 meters) 26-260-01
BNC-5-12’ MHR (12 feet/3.7 meters) 26-260-02
BNC-5-25’ MHR (25 feet/7.6 meters) 26-260-03
BNC-4-3’ MHR (3 feet/0.9 meters) 26-210-01
BNC-4-6’ MHR (6 feet/1.8 meters) 26-210-02
BNC-4-12’ MHR (12 feet/3.7 meters) 26-210-03
BNC-4-25’ MHR (25 feet/7.6 meters) 26-210-04
SVHS 6’ (6 feet/1.8 meters) 26-316-02
SVHS 12’ (12 feet/3.7 meters) 26-316-03
SVHS 20’ (20 feet/6.1 meters) 26-316-01
S-video male to 2 BNC adapter, female, 8” 26-353-02
S-video female to 2 BNC, male, 8” 26-353-01
SHR 1-3’ (3 feet/0.9 meters) 26-383-01
SHR 1-6’ (6 feet/1.8 meters) 26-383-12
SHR 1-12’ (12 feet/3.7 meters) 26-383-07
SHR 1-25’ (25 feet/7.6 meters) 26-383-04
