CAT 5 Receivers • Specifications, Accessories, and Part Numbers

CAT 5 Receivers • Specifications, Accessories, and Part Numbers

Specifications, Accessories, and Part Numbers cont’d

A-3

A-2

CAT 5 Receivers Specifications

Video

Number/signal type ................... 1 or 2 sets of proprietary analog signals
Connectors .................................... 1 or 2 RJ-45 female

Video input — refer to the CAT 5 Transmitters Family
User’s Manual, part #68-546-01

Video output

Number/signal type

CAT 5 R BNC A ............... 1 analog RGBHV, RGBS, RGsB,

component video, or S-video;
or 1 S-video and 1 NTSC/PAL/SECAM
composite video from a single source;
or 3 NTSC/PAL composite video from a
single source

CAT 5 R BNC AV ............ 1 analog RGBHV, RGBS, RGsB,

component video, or S-video;
or 1 S-video and 1 NTSC/PAL/SECAM
composite video from a single source;
or 3 NTSC/PAL/SECAM composite video
from a single source
and 1 NTSC/PAL/SECAM composite
video

CAT 5 R AV ...................... 1 NTSC/PAL/SECAM composite video

Connectors

CAT 5 R BNC A ............... 5 BNC female
CAT 5 R BNC AV ............ 6 BNC female
CAT 5 R AV ...................... 1 BNC female

Minimum/maximum levels ...... 0.3V to 1.45V p-p
Impedance .................................... 75 ohms

Audio

Number/signal type ................... 1 or 2 sets of analog proprietary signals
Connectors .................................... 1 or 2 RJ-45 female
Frequency response ..................... 20 Hz to 20 kHz, ±0.05dB
THD + noise ................................. 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated

maximum output drive (+19.5dBu input,
+21dBu output)

S/N ................................................ >90dB at output +21dBu
Crosstalk ....................................... >80dB @ 1 kHz, fully loaded

Stereo channel separation .......... >80dB @ 1 kHz
CMRR ............................................ >75dB @ 20 Hz to 20 kHz

Audio input — refer to the CAT 5 Transmitters Family
User’s Manual, part #68-546-01

Audio output

Number/signal type

CAT 5 R BNC A,
CAT 5 R AV ...................... 1 stereo audio balanced/unbalanced, and

1 stereo audio unbalanced

CAT 5 R BNC AV ............ 2 stereo audio balanced/unbalanced, and

2 stereo audio unbalanced

Connectors .................................... 2 female RCA (left/right) per input

1 3.5 mm, 5-pole captive screw connector
per input

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.1dB channel to channel
Maximum level (600 ohm) ......... >+14dBm, balanced at stated %THD+N

General

Power

CAT 5 R BNC A,
CAT 5 R AV ...................... 15VDC, 0.8A, external
CAT 5 R BNC AV ............ 100VAC to 240VAC, 50/60 Hz, 40 watts,

internal

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing

Rack mount

CAT 5 R AV ...................... No, but projector mountable with optional

mounting kit (#70-077-04), furniture
mountable with optional mounting
brackets (#70-077-01 and #70-077-02).

CAT 5 R BNC A,
CAT 5 R BNC AV ............ Yes, with optional 1U rack shelf, part

#60-190-01 and rack shelf mounting kit
#70-123-01. Also, projector mountable
with optional mounting kit, part
#70-077-04 or furniture mountable with
optional mounting brackets #70-077-01,
70-077-02.

Specifications, Accessories, and Part Numbers
