Xylem ECOCIRC XL, XLplus Electronic drive - Manual (Page 24)

0x0205 EXTERNAL WATER TEMPERATURE
0x0206 WINDING 1 TEMPERATURE
0x0207 WINDING 2 TEMPERATURE
0x0208 WINDING 3 TEMPERATURE
0x0209 POWER MODULE TEMPERATURE
0x020A QUADRATURE CURRENT
0x020B BIT FIELDS STATUS I/O
0x020C BIT FIELDS ALARM 1
0x020D BIT FIELDS ALARM 2
0x020E BIT FIELDS ERRORS
0x020F ACTIVE ERROR CODE
8.2.2.2 Information Table 2
It is a set of information [R] used for advanced use:
generally these data cannot be accessed through the
user interface.
MB. ADDRESS
(HEX)
INFORMATION DESCRIPTION
0x0230 MODBUS SLAVE ADDRESS
0x0231 WI-FI CLIENT/SERVER CONFIGURATION
0 = SERVER
1 = CLIENT
0x0232 PRESSURE SENSOR MODEL
0 = DIFF. PRESSURE SENSOR / Range 0 ÷ 1.0bar
1 = DIFF. PRESSURE SENSOR / Range 0 ÷ 2.0bar
0x0233 PROPORTIONAL PRESSURE MIN SETPOINT
0x0234 PROPORTIONAL PRESSURE MAX SETPOINT
0x0235 CONSTANT PRESSURE MIN SETPOINT
0x0236 CONSTANT PRESSURE MAX SETPOINT
0x0237 CONSTANT CURVE MIN SETPOINT
0x0238 CONSTANT CURVE MAX SETPOINT
0x0239 COMMUNICATION PROTOCOL
0 = MODBUS
1 = BACNET
0x023A BAUD RATE
8.2.2.3 Information Table 3
It is a set of information [R] used for twin pump use:
generally these data cannot be accessed through the
user interface, and are available to the Twin Master for
managing the pump: in fact this table is visible only in
case the drive is configured as a Twin Pump Master
(see par. 4.3.5.1)
MB. ADDRESS
(HEX)
INFORMATION DESCRIPTION
0x0260 TWIN SLAVE DRIVEN CURVE
0x0261 TWIN SLAVE START/STOP
0 = STOP
1 = START
0x0262 TWIN SLAVE INPUT POWER
0x0263 TWIN SLAVE HEAD [H]
0x0264 TWIN SLAVE FLOW [Q]
0x0265 TWIN SLAVE SPEED
0x0266 TWIN SLAVE WINDING 1 TEMPERATURE
0x0267 TWIN SLAVE WINDING 2 TEMPERATURE
0x0268 TWIN SLAVE WINDING 3 TEMPERATURE
0x0269 TWIN SLAVE POWER MODULE TEMPERATURE
0x026A TWIN SLAVE QUADRATURE CURRENT
0x026B TWIN SLAVE BIT FIELDS ALARM 1
0x026C TWIN SLAVE BIT FIELDS ALARM 2
0x026D TWIN SLAVE BIT FIELDS ERRORS
