APPENDIX A
____ 1. Is the unit base properly leveled, grouted and
secured?
____ 2. Are all lubrication points properly lubricated?
____ 3. Is the outlet side of the high temperature regulat-
ing valve connected to the drain with tubing or
pipe size 3/8" or greater?
____ 4. Is the shut-off valve to the pressure transmitter(s)
open?
____ 5. Is the shut-off valve to the pump suction open?
____ 6. Is the shut-off valve on the discharge line open?
____ 7. Is the bypass valve, if used, closed? This valve
may be left open if a check valve is installed in
series with it.
____ 8. Are the stop cocks for the check feature on the
PRV open? They must never be completely closed
during normal operation. Throttle cock if check
slamming is noted.
____ 9. Is the piping properly supported so as to prevent
strains on unit?
____ 10. Is the system, including the pumps and PRV’s,
purged of debris and air?
____ 11. Is the Hydro Pneumatic tank charged properly?
The tank must be empty of water when checking
the air charge.
____ 12. Are the bleed valves at the high temperature valve
header open?
APPENDIX B
APPENDIX B
____ 1. Does the feeder line voltage correspond to the unit
voltage? Check the unit nameplate or motor ter-
minal connection.
____ 2. Are the feeder wires correctly sized for the load?
____ 3. Are the fuses correctly sized? They must not
exceed 1.75 times the full load current of the
motor. Usual sizing is 1.15 to 1.5 times the full
load current.
____ 4. Is the unit properly grounded?
____ 5. Have all the power terminals in the control panel
been checked for tightness? This is imperative
since stranded wires tend to "flow" and become
loose after initial installation.
____ 6. Are motor overloads set properly? Set the over-
loads to FLA as a minimum and SF x FLA as a
maximum.
____ 7. Is the pump rotation correct?
CAUTION: Seal Damage may occur. Do not run
pumps dry. Fill and vent the pump volute prior to
operation.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD
RESULT IN PROPERTY DAMAGE AND/OR MODERATE
PERSONAL INJURY.
WARNING: Electrical shock hazard. Inspect all
electrical connections prior to powering the unit.
Wiring connections must be made by a qualified electrician
in accordance with all applicable codes, ordinances, and
good practices.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD
RESULT IN SERIOUS PERSONAL INJURY, DEATH,
AND/OR PROPERTY DAMAGE.
WARNING: Conduit grounds are not adequate. A
separate ground wire must be attached to the ground
lug provided in the enclosure to avoid potential safety
hazards.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD
RESULT IN SERIOUS PERSONAL INJURY, DEATH,
AND/OR PROPERTY DAMAGE.
DANGER: High Voltage 3 phase power can kill.
Disconnect and lockout power prior to servicing unit.
FAILURE TO FOLLOW THESE INSTRUCTIONS WILL
RESULT IN SERIOUS PERSONAL INJURY, DEATH,
AND/OR PROPERTY DAMAGE.
ELECTRICAL WIRING AND CONTROL SETTINGS - FINAL CHECK LIST
SYSTEM PIPING AND UNIT INSTALLATION - FINAL CHECK LIST
