Page 31
Pipe plug torque values
Table 2: Pipe plug torque, ft-lb (Nm)
Size
Turns past finger tight
Approximate torque
1/8 in NPT
1.5 to 3
12 (16)
1/4 in NPT
1.5 to 3
25 (34)
3/8 in NPT
1.5 to 3
40 (54)
1/2 in NPT
1.5 to 3
54 (73)
Dealer servicing
If trouble occurs that cannot be rectified, contact your local sales and service
representative and be prepared to provide this information:
1. Complete nameplate data of pump and motor
2. Suction and discharge pipe pressure gauge readings
3. Ampere draw of the motor
4. A sketch of the pump hook-up and piping
Maintenance
Series e-1532 INSTRUCTION MANUAL
29
