Mechanic dimensions, Chatter unit for pipe mounting, Chatter unit for wall mounting – Xylem CHATTER Hardware Manual User Manual
Page 33: Data logger
10. Mechanic Dimensions
Chatter Unit for Pipe Mounting
150 mm
101 mm
190 mm
Ø 63 - 106 mm
Indre rørdiameter
190
150
101
Inner pipe diameter
Ш63 - Ш106
Figure 24. Mechanic Dimensions - Pipe Mounted
Chatter Unit for Wall Mounting
14
4
156
83
79
Figure 25. Mechanic Dimensions - Wall Mounted
10. Mechanic Dimensions
Data Logger
33
