5. Mounting
MJK Chatter data logger is supplied in two different mounting versions: one
for pipe mounting and one for wall mounting (mounting on wall or cabinet).
5.1 Pipe Mounting
Necessary tools and parts:
• Wedge set to fit pipe diameter
• Socket spanner, 7 mm
1. Activate the Chatter unit(s) as described in section 9. Physical Activation
on page 31 .
2. Re-assemble the Chatter unit(s) as described in section
6.2 Wall Mounting on page 23 .
3. Prepare the Chatter base with wedges to fit the pipe diameter:
Wedge From inner diameter ----> to inner diameter
Wedge 1 Ø63 mm Ø71 mm
Wedge 2 Ø70 mm Ø78 mm
Wedge 3 Ø77 mm Ø85 mm
Wedge 4 Ø84 mm Ø92 mm
Wedge 5 Ø91 mm Ø99 mm
Wedge 6 Ø98 mm Ø106 mm
Table 8. Wedge Sizes
