Electrical and mechanical mounting and connecting – Xylem MY CONNECT HMI display User Manual
Page 8
MANUAL
HMI display
8
Electrical and mechanical mounting and connecting
The HMI display provides the following connection options:
1. Audio Line Out - 3.5 mm jack
2. SD Card Slot SDHC
3. COM1 RS-232 2W/4W
4. COM3 RS-485 2W Supports MPI 187.5K
5. Ethernet Port 10/100 Base-T
6. USB Host USB 2.0
7. USB Client USB 2.0
