MANUAL
HMI display
5
Specifications & Order Numbers
MJK HMI Display
Power supply 24V DC ±20%
Power consumption 400 m A@24V
Processor 32Bit RISC CPU 600MHz
Display 7” TFT / Resolution 800 x 480 pixels (W x H)
Memory 256MB / RAM 256MB
Brigtness (cd/m2) 500 / Contrast Ratio 500:1 / 16.7M Colors
LED Back Light Back Light Life Time >30.000 hrs
Touch Panel 4-Wire Resistive Type
External
Communication CAN bus / CANopen Protocol / Modbus RTU
Interface SD Card Slot SDHC
Audio Line Out - 3.5 mm jack x 1
USB Host USB 2.0 x 1 / USB Client USB 2.0 x 1
Ethernet Port 10/100 Base-T
COM Port COM1 (RS-232/RS-485 2W/4W), COM3(RS-232/RS-485 2W) Supports MPI 187.5K
Enclosure IP66 front panel (O ring seal) / NEMA 4
Cabinet Material Aluminum
Operating Conditions -20°~50°C (-4°~122°F)
Storage Temperature -20°~70°C (-4°~158°F)
Operation Humidity 10%~90% RH (non-condensing)
Weight App. 0.9 kg.
Dimensions Panel
Cutout 192 x 138 mm (W x H)
Approvals Compilies with EN 55022:2006+A1:2007 , EN 61000-3-2:2006+A2:2009 .EN 61000-3-3:2008,
EN 55024:1998+A1:2001+A2:2003
Comply with FCC class A
