MANUAL
HMI display
34
Level
Menu Item Option Default Description
Level sensor at
20 mA -99 - 999 Depen
ding on
sensor Adjust level hight when level sensor provides 20 mA. Select to adjust.
Level sensor at
4 mA -99 - 999 Depen
ding on
sensor Adjust level hight when level sensor provides 4 mA. Select to adjust.
Level maximal -99 - 999 Depen
ding on
sensor Adjust setpoint limitation in relation to max level. Select to adjust.
Level minimal -99 - 999 Depen
ding on
sensor Adjust setpoint limitation in relation to max level. Select to adjust.
Level high alarm Select to
adjust Set level for high alarm
Level low alarm Select to
adjust Set level for high alarm
