5
level in menu 6.6.3.
LEVEL 1 SET 1.90
RESET 1.70
When adjusting a level, press one of the arrow keys,
consequently the setting will flash. Set the wanted value
with the arrow keys and confirm with ENTER. Double
arrow alters the value quickly, single arrow alters the
value slowly.
The highest value acceptable is the equivalent of the max.
level which has been programmed in menu 5.7. The
lowest value acceptable is 1% of the measuring range of
the sensor (reading in menu 5.1). The lowest range
acceptable between start and stop is 1% of the max. level
programmed into menu 5.7.
NB: If level indication with elevation is applied, the values
must be keyed in according to the elevation.
F6 Forced start
F7 Forced stop
Forced controlling is carried out by pressing one of the
keys 1-4 as well as the corresponding key for either start
or stop.
If the level is between the start and stop levels the pumps
stay started or stopped when the keys are released.
Above or below the interval between the start and stop
levels, the pump is only started/stopped while the keys are
pressed. The same applies if the level is not in use (menu
6.7.2).
If a pump which is configured for alternating control is run
forced, it is run as directly controlled during the forced
running. As soon as the forced running is stopped the
pump returns to alternating operation.
Programming of pump controller
When function F0 shows in the display press the MENU
key for access to the programming menus (if code is not
applied, see menu 3.3). Change between the main menus
by repeatedly pressing the MENU key. Press ENTER to
change to sub menus. Make choices and adjustments in
the sub menus with the arrow keys and confirm with
ENTER.
1.0 Language
Choose between languages with the arrow keys.
2.0 Key in access code
If access code has been chosen, key it into this menu
before the following menus become accessible. Key in
code with keys 1-4. Do not confirm with ENTER.
When the code is keyed in, access is given to make
alterations of all settings for 10 minutes after last key is
pressed.
3.0 Programming of main functions
Access to the configuring menus are obtained by pressing
MENU.
3.1 Access code wanted / not wanted
Choose here if access code is to be used for gaining
access to the pump controller. If code is selected, it is not
allowed to change the settings.
3.2 Key in new access code
If a new access code is wanted, key it into this menu. If
the code is to remain unchanged press the MENU key.
3.3 Code only setup / all adjustments
The code can be chosen to only block the setup i.e.
menues which are made accessible with the MENU key.
Or it can be set to block all settings i.e. also start and stop
settings for levels as well as reset of counters.
If a code has been chosen for all settings, alterations are
made by entering menu 2.0 and keying in the code, now
access is given to make alterations of all settings for 10
minutes after last key is pressed.
4.0 Measurement level / levels + elevation
Setting of level indication either as absolute measurement
or relative measurement according to a given elevation.
An altitude is the level reset-point which is valid on the
relevant location, e.g. the elevation of the pumping station
above the sea. I.e., if a pumping station is placed 1.25 m
above the surface of the sea, and this is keyed in as an
elevation, a level measurement of 2.25 m will be indicated
as 3.50 m.
If level indication with elevation has been chosen, all start
/ stop values are programmed according to the elevation.
