4
P2 RESET TIME-COUNTER?
YES: ENTER NO:MENU
F2 Capacity / Quantity
If key 1-4 is pressed while F1 is in the functional display,
menu F2 will show:
P2 CAPACITY 82 m 3 /h
QUANTITY 5508 m 3
The capacity of each single pump is shown at this point,
as well as the pumped out volume. When pressing the
MENU-key while functional indication F2, access is given
to reset the capacity and water quantities (if code is not
applied, see menu 3.3):
P2 RESET CAPACITY
YES: ENTER NO:MENU
P2 RESET QUANTITY
YES: ENTER NO:MENU
F3 Pumping station volume
When pressing key 1-4 while functional indication F2
shows on the display, menu F3 will appear:
PUMPING STATION
QUANTITY 27803 m 3
Displayed here is the pumped out volume for the entire
pumping station, as the sum of the pumped out volumes
from all the individual pump’s. If the MENU key is
pressed, the volume can be reset:
P2 RESET QUANTITY
YES: ENTER NO:MENU
F4Level Start/Stop
F5 Level Set/Reset
By pressing START or STOP keys, the levels activating
the relays can be read. If the relay is configured for
controlling, the levels for starting and stopping the pump
can be read. If the relay is configured as an alarm, the
levels for setting and resetting can be read.
If the pump controller is configured for filling (see menu
6.1) the start level will be lower than the stop level, and
vice versa if the pump controller is configured for
emptying.
LEVEL 2 START 1.80
STOP 0.20
If the relay is configured as a level alarm, there is an
alternative choice of adjusting the set levels to be either
higher (high alarm) or the contrary (low alarm) to the reset
Operation of pump controller
The keys under the display give access to the functions
used in the daily operation. The MENU key gives access
to programming of the pump controller. The programming
can be locked separately with an access code i.e. a code
must be keyed in, in order to get access to the
programming menus.
Functional indications
When the pump controller is connected to 230 V, the
display will show:
PROGRAM 8340XX
STARTUP WAIT A MOMENT
If the pump controller is activated for the first time, the
display will show the following:
KEY IN NEW VALUES
PRESS ENTER
Now the pump controller can be configured. The settings
can always be altered later on.
If the sensor type is changed, or if an output relay is either
put into service or out of service, the programme will reset
and new values must be keyed in.
F0 Level measuring
When the programming is carried out, function F0, level
measuring in the display is shown:
MEASURING 1.50 m
If the pump controller is set up for level output according
to a given elevation, both the level and the level relative to
the elevation is shown in the display:
MEASURING 1,50 m
ELEVATION 1,65 m
F1 Starts / Operational time
By pressing one of the keys 1-4 number of starts are
shown, as well as operation time for any of the relays 1-4
in use. If the relay is configured for operational relay the
relay number is shown with a prepositive P for pumps. If
the relays are configured as alarms an A will show:
P2 STARTS 4
OPERATIONAL TIME 2.9 h
If the MENU-key is pressed while the functional indication
F0 is in the display, access is given to reset the counter
and time counter:
P2 RESET COUNTER?
YES: ENTER NO:MENU
