CL500 (2/08) Page 2
REV 2.0
1.0 Overview
The CL500 Online Chlorine Analyzer allows for the reading of chlorine levels of process
water on-line. The CL500 has been designed to meet the design criteria specified by
Standard Methods for the Examination of Water and Wastewater (21th Edition) Method
4500-Cl G. DPD Colorimetric Method. The CL500 uses a 515nm LED as the
measurement light source.
Every effort has been made to ensure the accuracy of this manual. Due to the continuous
development and improvement of all instrumentation, there may be slight differences
between this manual and the instrument received. Therefore, no legal claims can be made
against any discrepancies herein. The latest version of the manual can be downloaded
from
www.globalw.com .
1.1 Unpacking and Inspection of the Instrument and Accessories
The table below indicates the items in the shipment.
Item Quantity
CL500 Analyzer 1
Instruction Manual 1
Mounting Kit 1
Tubing/Cuvette Kit: 8 black “B” tubes, 2 Cap Assemblies, 1 replacement cuvette 1
In-Line Strainer Kit 1
Ferrite 1
Remove the instrument from the packing carton. Carefully inspect all items to ensure that
no visible damage has occurred during shipment. If the items received do not match the
order, please immediately contact the local distributor or Global Water’s Customer
Service Department.
