Technical data

IFL 70x IQ

7 - 2

ba76129e01

10/2012

7.3

General data

Dimensions (in mm)

Weight (without sensor

connection cable)

Connection technique

Connection via SACIQ (SW) sensor connection cable

Material

Cleaning system

(only IFL 700 IQ)

Mechanical wiper, maintenance-free

Instrument safety

Ш 60

Ш 105

Marking

for

immersion depth

100 mm

442

255

533

IFL 700 IQ

3.9 kg

IFL 701 IQ

3.7 kg

Shaft and enclosure

V4A stainless steel 1.4571
POM

Base plate

V4A stainless steel 1.4571

Ultrasonic transducer surface

PVC-C

Wiper (only IFL 700 IQ)

Grivory

Wiper driving shaft
(only IFL 700 IQ)

Titan (grade 2)

Plug head connector housing

POM

Plug, 3-pole

ETFE (blue) Tefzel

®

Applicable norms

– EN 61010-1
– UL 61010-1
– CAN/CSA C22.2#61010-1
