Appendix B
AQUAVAR Model 56 Controller Drive Head Technical Data
AQUAVAR Model 56
Supply Motor
Voltage
Controller Protection
Type Rated output Voltage
AV 1.1 1 HP 1 x 230 V / 40-60 Hz 3 x 230 V 4,8 A 10 Ampere
AV 1.15 2 HP 1 x 230 V / 40-60 Hz 3 x 230 V 7,0 A 10 Ampere
AV 1.2 3 HP 1 x 230 V / 40-60 Hz 3 x 230 V 10,0 A 16 Ampere
Input Voltage: 1 x 230 VAC ± 10% (An input line reactor is highly recommended
for areas which experience voltage fluctuation.)
Output Voltage: 3 x 230 Volt AC
Max. Frequency: 40 – 60 Hz – selectable
Min. Frequency: 0 - f-max
Electrical Efficiency: > 95%
Protection against: Short circuit, under-voltage, overheating of the electronics (overload) and
additional protective functions via external switch (motor temperature,
low water).
A power supply filter is included to ensure interference immunity.
The AV Series frequency converter complies with the general EMV provisions and has been tested according
to the following standards:
• Radio Interference Suppression EN 50081 Part 2 and EN 50082 Part 2
• High Frequency Field Interference ENV 50140 and ENV 50141
• Static Electricity Discharge EN 61000-4
• Disturbance Voltage EN55011
Ambient Temperature: 5° C – 40° C
Storage Temperature: -25° C – +55° C
(+70° C during max. 24 hours)
Humidity: rH max. 50% at 40° C, unlimited
RH max. 90% at 20° C, max. 30 days per year
Condensation not permitted!
Air Pollution: The air may contain dry dust as found in workshops where there is no
excessive quantity of dust due to machines. Excessive amounts of dust,
acids, corrosive gases, salts, etc. are not permitted.
Class of Protection: UL, CUL, NEMA 4, IP 55
Altitude: Maximum 3000 feet above sea level. Consult factory for higher altitudes.
