Submenu Error The inverter tries to reach a
defined pressure limit in a defined time. If this is not
possible the inverter stops. To enter this
menu you have to press the key, to leave
the menu, press the ➔ key longer than 3
seconds.
Conveyor Limit Disabled or adjustable
between 0.00 and 100%. To disable the
conveyor limit, press till “0.0%” is shown
on the display. To set a % pressure the
or .
Error Delay Adjustable between 0 and
100 sec. Delayed switch-off in the event of low
water, (suction side switch connected to
terminal X2/6-X2/7) and also for the conveyor limit.
Time Setting.
To leave the submenu press the ➔ key for longer than 3 seconds.
Set Password The pre-set password can be
changed if necessary with the and keys.
Default Settings To load DEFAULT –
PARAMETER, press buttons + together,
until the timer is run down.
Submenu Diagnosis To enter this menu you
have to press the key, to leave the menu,
press the ➔ key longer than 3 seconds.
Pump Runtime Shows the run time of
the pump.
Pump Address This window shows the
adjustment of the pump address, Read Only.
* The last three error signals are always stored with Signal Error 1 to 3.
* The error signals can not be deleted.
* The signal ERROR 1 shows the last error to have occurred.
Operator Custom Features and Displays
35
SUBMENU
ERROR
CONVEYOR LIMIT
0.0%
ERROR DELAY
2 SEC.
SET PASSWORD
0066
DEFAULT
+
SUBMENU
DIAGNOSIS
PUMP RUNTIME
0000 STD.
PUMP-ADDRESS
1
➔
➔
