Operator Custom Features and Displays
LAST ERROR:
Error before the last error:
Error before error 2:
Software Version This parameter shows the software
version of the AQUAVAR Model 56 Controller.
To leave the submenu press the key for 3 seconds.
Set Password Here the set or changed
password is confirmed.
Controller Menu
Controller menu Configuration To enter this
menu you have to press the key, to leave
the menu, press the ➔ key longer than
3 seconds.
Automatic connection to the programming
device Only valid for programming device!
Autoconnecting enabled means that after plug in of
the programming device, it changes automatically to
the converter menu. During this auto connection
“SCAN CONNECTION” is shown on the display.
ATTENTION! Autoconnecting will be stored
after leaving the submenu Configuration. If
autoconnection is enabled, do not plug the
programming device into an AQUAVAR Model 56
Controller which runs in the multi-controller mode
together with other AQUAVAR Model 56 Controller
pumps via the RS485-interface.
Software Version In the second line of
the display, the version of the software for the
programming Device is shown and also
the software date.
To leave the submenu press the ➔ key for longer than 3 seconds.
36
LAST ERROR
2
ND
ERROR
3
RD
ERROR
SOFTWARE
CP – VOG: 001
PASSWORD
O.K.
SUBMENU
CONFIGURATION
AUTO CONNECTING
ENABLED
➔
➔
SOFTWARE:
SOFTWARE: CP-VOG: 004
