APPENDIX
“A”
REPLACEMENT PARTS LIST
PART NUMBER
PART NAME
QUANTITY
PACKING
MECH. SEAL
0-901-0
Valve
2 (optional)
2
0-910-0
Pipe Plug
20
18
0-950-0
Pipe Nipple
2 (optional)
2
0-952-0
Tubing
2 (optional)
2
1-013-2
Seal Cage
2
1-014-2
Gland (Packing)
2
1-428-1
Sleeve Gasket
2
2
1-904-9
Gland and Housing Bolt
12
8
1-909-9
Washer, Gland Bolt
4
1-924-9*
Packing Ring
12
2-001-7
Casing, Upper Half
1
1
2-001-8
Casing, Lower Half
1
1
2-123-5*
Casing Joint Gasket (Suction)
1
1
2-133-6*
Casing Joint Gasket (Discharge)
1
1
2-904-1
Cap Screw (Casing)
Varies with pump size
Varies with pump size
2-916-9
Taper Pin
2
2
3-003-9*
Casing Ring
2
2
3-007-0
Shaft
1
1
3-009-9*
Shaft Sleeve
2
2
3-014-2
Gland (Mechnical Seal)
2
3-015-9
Shaft Sleeve Nut
2
2
3-018-3
Bearing Housing Cover (Inboard)
1
1
3-018-4
Bearing Housing Cover (Outboard)
1
1
3-025-2
Bearing Housing
2
2
3-026-2*
Bearing
2
2
3-078-9
Thrust Washer (Outboard)
1
1
3-136-9
Deflector
2
2
3-177-4*
Lip Seal (Outboard Bearing)
1
1
3-177-9*
Lip Seal (Bearing)
3
3
3-401-0*
Mechanical Seal Seat
2
3-402-0*
Mechanical Seal Head
2
3-409-9
Gasket (Bearing Housing Cover)
2
2
3-516-4
Locknut
1
1
3-517-4
Lockwasher
1
1
3-902-9
Set Screw (Shaft Sleeve Nut)
2
2
3-904-9
Gland and Cover Bolt
4
8
3-911-1
Key (Impeller)
1
1
3-911-2
Key (Coupling)
1
1
3-911-3
Key (Shaft Sleeve)
2
2
3-914-2*
O-Ring (Gland)
2
3-914-9*
O-Ring (Shaft Sleeve)
2
2
3-915-9
Snap Ring
2
2
3-943-9
Spirol Pin
2
2
4-002-0
Impeller
1
1
4-004-9
Impeller Ring
2 (optional)
2 (optional)
*Recommended Spare Parts.
