1 System tour 10
10 LAN1 Gigabit Ethernet port 1
11 FAN8 Chassis fan 8
12 VGA Video port
13 P1 DIMM DDR3 DIMM slots for processor 1
14 COM1 Serial port 1
15 IPMI/LAN/USB0/USB1 Dedicated IPMI LAN port/rear USB ports
16 Keyboard/Mouse PS/2 keyboard and mouse ports
17 CPU3 Processor 3 socket
18 FAN7 Processor 3 fan
19 P3 DIMM DDR3 DIMM slots for processor 3
20 FAN1 Processor 4 fan
21 JF1 Front panel board connector
22 CPU4 Processor 4 socket
23 P4 DIMM DDR3 DIMM slots for processor 4
24 FAN2 Chassis fan 2
25 FAN3 Chassis fan 3
26 FAN4 Processor 2 fan
27 CPU2 Processor 2 socket
28 P2 DIMM DDR3 DIMM slots for processor 2
29 FAN5 Chassis fan 5
30 FAN6 Chassis fan 6
31 JPW1 24-pin main ATX power connector
32 JPW4 +12V 8-pin power connector
No. Code Component
