NE555/SA555/NA555
PRECISION TIMERS
NE555/SA555/NA555
Document number: DS35112 Rev. 4 - 2
3 of 14
February 2012
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings
(Note 2)
@ T
A
= 25
°C unless otherwise stated
Symbol
Parameter
Rating
Unit
V
CC
Supply voltage (Note 3)
18
V
V
I
Input voltage
CONT, RESET, THRES, TRIG
V
CC
V
I
O
Output current
±225
mA
θ
JA
Package thermal resistance Junction-to-Ambient
(Note 4)
130
°C/W
θ
JC
Package thermal resistance Junction-to-Case
(Note 5)
15
°C/W
T
J
Junction temperature
150
°C
T
STG
Storage temperature
-65 to 150
°C
Recommended Operating Conditions
(T
A
= 25
°C)
Symbol
Parameter
Min
Max
Unit
V
CC
Supply voltage
4.5
16 V
V
I
Input voltage
CONT, RESET, THRES, TRIG
V
CC
V
I
O
Output current
±200 mA
T
A
Operating Ambient Temperature
NE555 0
70
°C
SA555 -40
85
NA555 -40
105
Notes: 2. Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings only.
Functional operation of the device at these or any other conditions beyond those indicated under "recommended operating conditions" is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
3. All voltage values are with respect ground.
4. Maximum power dissipation is a function of T
J
(max),
θ
JA
, and T
A
. The maximum allowable power dissipation at any allowable ambient temperature
is P
D
= (T
J
(max) – T
A
)/
θ
JA
. Operating at the absolute maximum T
J
of 150°C can affect reliability.
5. Maximum power dissipation is a function of T
J
(max),
θ
JC
, and T
A
. The maximum allowable power dissipation at any allowable ambient temperature
is P
D
= (T
J
(max) – T
C
)/
θ
JA
. Operating at the absolute maximum T
J
of 150°C can affect reliability.
Electrical Characteristics
(V
CC
= 5V to 15V, T
A
= 25°C unless otherwise stated)
Symbol
Parameter
Test conditions
Min
Typ.
Max
Unit
V
TH
Threshold voltage level
V
CC
= 15V
8.8 10 11.2
V
V
CC
= 5V
2.4 3.3 4.2
I
TH
Threshold current
(Note 6)
30
250
nA
V
TR
Trigger voltage level
V
CC
= 15V
4.5 5 5.6
V
V
CC
= 5V
1.1 1.67 2.2
I
TR
Trigger current
TRIG at 0V
0.5
2
µA
V
RST
RESET voltage level
0.3
0.7
1
V
I
RST
RESET current
RESET at V
CC
0.1
0.4
mA
RESET at 0V
-0.4
-1.5
I
DIS
DISCH switch off-state current
20
100
nA
V
DIS
DISCH saturation voltage with
output low (Note 7)
V
CC
= 15V, I
DIS
= 15mA
180
480
mV
V
CC
= 5V, I
DIS
= 4.5mA
80
200
V
CON
CONT voltage (open circuit)
V
CC
= 15V
9 10 11
V
V
CC
= 5V
2.6 3.3 4
