PAM8406
A Product Line of
Diodes Incorporated
Electrical Characteristics
(cont.)
(@T
A
= +25°C, V
DD
= 5V, Gain = 24dB, R
L
= 8Ω, both Class-AB and D mode, unless otherwise specified.)
Symbol Parameter
Test
Conditions
Min
Typ
Max
Units
I
MUTE
Muting Current
V
DD
= 5.0V
V
MUTE
= 0.3V
2.4 mA
I
SD
Shutdown Current
V
DD
= 2.5V to 5.5V
V
SD
= 0.3V
<
1 µA
R
DS(ON)
Static Drain-to-Source
On-State Resistor
I
DS
= 500mA, V
GS
= 5V
PMOS
180
mΩ
NMOS
140
f
SW
Switching Frequency
V
DD
= 2.5V to 5.5V
Class-D
250 kHz
V
OS
Output Offset Voltage
Input AC-GND, V
DD
= 5.0V
10 mV
V
IH
Enable Input High
Voltage
V
DD
= 5.0V
1.4
V
V
IL
Enable Input Low
Voltage
V
DD
= 5.0V
0.4
V
IH
MUTE Input High
Voltage
V
DD
= 5.0V
1.4
V
V
IL
MUTE Input Low
Voltage
V
DD
= 5.0V
0.4
V
IH
MODE Input High
Voltage
V
DD
= 5.0V
1.4
V
V
IL
MODE Input Low
Voltage
V
DD
= 5.0V
0.4
OTP
Over Temperature
Protection
No Load, Junction Temperature
V
DD
= 5.0V
150
°C
OTH
Over Temperature
Hysterisis
30
