PAM8406
Document number: DSxxxxx Rev. 1 - 0
3 of 14
March 2013
© Diodes Incorporated
PAM8406
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating
Unit
Supply Voltage
6.0
V
Input Voltage
-0.3 to V
DD
+0.3V
Operation Temperature Range
-40 to +85
°C
Maximum Junction Temperature
150
Operation Junction Temperature
-40 to +125
Storage Temperature
-65 to +150
Soldering Temperature
300, 5 sec
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating
Unit
Supply Voltage Range
2.5 to 5.5
V
Operation Temperature Range
-40 to +85
°C
Junction Temperature Range
-40 to +125
°C
Thermal Information
Parameter Package
Symbol
Max
Unit
Thermal Resistance (Junction to Ambient)
SOP-16
θ
JA
110
°C/W
Thermal Resistance (Junction to Case)
SOP-16
θ
JC
23
