Electrical Characteristics
(T
A
= +25°C, V
IN
= 3.3V, V
OUT
= 5V, L = 2.2µH, unless otherwise noted.)
PARAMETER SYMBOL Test Conditions Min Typ Max Units
Input Voltage Range V
IN
No load, V
O
= 5V 0.9 4.75 V
I
O
=1A , V
O
= 5V 2.7 4.75
Minimum Startup Voltage V
STARTUP
I
O
= 0.1A, V
O
= 3.3V 1 V
Shutdown Supply Current I
SD
0.1 1 µA
Quiescent Current Iq
No load, switching (measured with
external feedback); V
O
= 5V
150 µA
Oscillator Frequency f
OSC
0.8 1 1.2 MHz
Maximum Duty Cycle D
MAX
87.5 %
Output-Voltage Adjust Range V
O
2.5 5 V
FB Regulation Voltage V
FB
No Load 0.588 0.6 0.612 V
Load Regulation LDR I
OUT
= 1mA to 1000mA 2.5 %
Line Regulation LNR V
O
= 2.5V to 4.75V, I
O
= 0.5A 0.3 %/V
Drain-Source On-State Resistance R
DS(ON)
P MOSFET 150 250 mΩ
N MOSFET 100 170 mΩ
N-Channel Current Limit (Note) I
LIMIT
R
SET
Floating or R
SET
> 200KΩ 3 A
R
SET
= 100KΩ 1.5 A
R
SET
= 66KΩ 1 A
Pre-charge Current I-Charge V
OUT
+0.5V < V
IN
500 mA
Pre-charge Time T-Charge V
OUT
+0.5V < V
IN
400 µs
SW Leakage Current ILSW 0.1 2 µA
Power Good Threshold VPG 92 %
EN Threshold High
V
H
V
IN
= 0.9V 0.8
V
V
H
V
IN
= 3.3V 1.5
EN Threshold Low V
L
V
IN
> 1.2V 0.2 V
Over Temperature Threshold TOTSD 160 °C
Over Temperature Hysteresis THYS 50 °C
Note: N-Channel current limit is guaranteed by design.
