PAM2401
NEW PROD
UC
T
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating
Unit
Input Voltage
-0.3 to +6.0
V
SW Voltage
-0.3 to +6.0
V
SHDN, FB Voltage
-0.3 to +6.0
V
V
OUT
-0.3 to +6.0
V
Operating Temperature Range
-40 to +85
°C
Storage Temperature Range
-65 to +125
°C
Lead Temperature (Soldering, 10 sec)
300
°C
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating
Unit
Ambient Temperature Range
-40 to +85
°C
Junction Temperature Range
-40 to +125
Thermal Information
Parameter Package
Symbol
Max
Unit
Thermal Resistance
(Junction to Case)
MSOP-8
Θ
JC
75
°C/W
U-DFN3030-12 8.5
Thermal Resistance
(Junction to Ambient)
MSOP-8
Θ
JC
180
U-DFN3030-12 60
Internal Power Dissipation
MSOP-8
P
D
0.55
W
U-DFN3030-12 1.66
