Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
80
⎯
⎯
V
I
C
= 100
μA, I
E
= 0
Collector-Emitter Breakdown Voltage (Note 8)
BV
CEO
80
⎯
⎯
V
I
C
= 1mA, I
B
= 0
Emitter-Base Breakdown Voltage
BV
EBO
4
⎯
⎯
V
I
E
= 100
μA, I
C
= 0
Collector-Base Cutoff Current
I
CBO
⎯
⎯
100 nA
V
CB
= 80V, I
E
= 0
Collector-Emitter Cutoff Current
I
CES
⎯
⎯
100 nA
V
CE
= 60V, I
B
= 0
ON CHARACTERISTICS (Note 8)
DC Current Gain
h
FE
100
⎯
⎯
⎯
I
C
= 10mA, V
CE
= 1V
100
⎯
⎯
I
C
= 100mA, V
CE
= 1V
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
0.25 V
I
C
= 100mA, I
B
= 10mA
Base-Emitter Turn-On Voltage
V
BE(on)
⎯
⎯
1.20 V
I
C
= 100mA, V
CE
= 1V
SMALL SIGNAL CHARACTERISTICS
Current Gain-Bandwidth Product
f
T
100 163
⎯
MHz
V
CE
= 2V, I
C
= 10mA, f = 100MHz
Output Capacitance
C
obo
⎯
7
⎯
pF
V
CB
= 10V, f = 1MHz
Note:
8. Measured under pulsed conditions. Pulse width
≤ 300μs. Duty cycle ≤ 2%.
