Diodes DRD (xxxx) W - Manual (Page 8)

0
0.5
1
2.5
2
1.5
3
0 10 20 30 40
C
,
T
O
T
AL
C
A
P
A
C
IT
A
N
C
E (p
F
)
T
V , REVERSE VOLTAGE (V)
Fig. 19, Typical Capacitance vs. Reverse Voltage
(Switching Diode)
R
f = 1MHz
Ordering Information
(Note 5)
Device Packaging Shipping
DRDN010W-7 SOT-363 3000/Tape & Reel
DRDP006W-7 SOT-363 3000/Tape & Reel
DRDNB16W-7 SOT-363 3000/Tape & Reel
DRDNB26W-7 SOT-363 3000/Tape & Reel
DRDPB16W-7 SOT-363 3000/Tape & Reel
DRDPB26W-7 SOT-363 3000/Tape & Reel
DRDN005W-7 SOT-363 3000/Tape & Reel
Notes: 5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
RDxx = Product Type Marking Code:
RD01 = DRDN010W
RD02 = DRDP006W
RD03 = DRDNB16W
RD04 = DRDNB26W
RD05 = DRDPB16W
RD06 = DRDPB26W
RD07 = DRDN005W
YM = Date Code Marking
Y = Year ex: S = 2005
M = Month ex: 9 = September
RDxx
YM
Date Code Key
Year 2005 2006 2007 2008 2009 2010 2011 2012
Code S T U V W X Y Z
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
