DESDALC5LP
Document number: DS36761 Rev. 2 - 2
4 of 6
May 2014
© Diodes Incorporated
DESDALC5LP
ADVAN
CE I
N
F
O
RM
ATI
O
N
ADVANCED INFORMATION
Figure 9 ESD Response to IEC 6100-4-2
(+8kV Contact Discharge)
Figure 10 ESD Response to IEC 6100-4-2
(-8kV Contact Discharge)
Figure 11 ESD Response to IEC 6100-4-2
(+15kV Contact Discharge)
Figure 12 ESD Response to IEC 6100-4-2
(-15kV Contact Discharge)
(1) ESD Peak
(2) Clamp Voltage @ 30ns
(3) Clamp Voltage @ 60ns
(4) Clamp Voltage @ 100ns
(1) 72V
(4) 16V
(3) 19V
(2) 21V
50ns/div
50V/div
(1) -76V
(4) -12V
(3) -10V
(2) -12V
(1) ESD Peak
(2) Clamp Voltage @ 30ns
(3) Clamp Voltage @ 60ns
(4) Clamp Voltage @ 100ns
50ns/div
50V/div
(1) 125V
(4) 19V
(3) 19V
(2) 22V
(1) ESD Peak
(2) Clamp Voltage @ 30ns
(3) Clamp Voltage @ 60ns
(4) Clamp Voltage @ 100ns
50ns/div
50V/div
(1) ESD Peak
(2) Clamp Voltage @ 30ns
(3) Clamp Voltage @ 60ns
(4) Clamp Voltage @ 100ns
(1) -133V
(4) -10V
(3) -13V
(2) -17V
50ns/div
50V/div
F (Hz)
Figure 13 S21 Attenuation Measurement Result
-40
-35
-30
-25
-20
-15
-10
-5
0
100k
1M
100M
1G
dB
10M
0
5
10
15
20
0
5
10
15
20
25
Pin 2 to Pin 1
Pin 1 to Pin 2
TLP Plot
Pulse with 100ns
I (
A
)
PP
V (V)
CL
Figure 14 TLP Measurement
