DMC3032LSD
Document number: DS32153 Rev. 1 - 2
1 of 8
May 2010
© Diodes Incorporated
DMC3032LSD
NEW PROD
UC
T
COMPLEMENTARY PAIR ENHANCEMENT MODE MOSFET
Features
• Low
On-Resistance
• N-Channel:
32m
Ω @ 10V
46m
Ω @ 4.5V
• P-Channel:
39m
Ω @ 10V
53m
Ω @ 4.5V
•
Low Input Capacitance
•
Fast Switching Speed
•
Low Input/Output Leakage
• Complementary
Pair
MOSFET
•
Lead Free/RoHS Compliant (Note 1)
•
"Green" Device (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SO-8
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals Connections: See Diagram
•
Terminals: Finish - Matte Tin annealed over Copper lead frame.
Solderable per MIL-STD-202, Method 208
•
Marking Information: See Page 6
•
Ordering Information: See Page 6
•
Weight: 0.072 grams (approximate)
Maximum Ratings N-CHANNEL – Q1
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Drain-Source Voltage
V
DSS
30 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 3)
Steady
State
T
A
= 25°C
T
A
= 85°C
I
D
8.1
5.1
A
Pulsed Drain Current (Note 4)
I
DM
25 A
Maximum Ratings P-CHANNEL – Q2
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Drain-Source Voltage
V
DSS
-30 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 3)
Steady
State
T
A
= 25°C
T
A
= 85°C
I
D
-7.0
-4.5
A
Pulsed Drain Current (Note 4)
I
DM
-25 A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Power Dissipation (Note 3)
P
D
2.5 W
Thermal Resistance, Junction to Ambient (Note 3)
R
θJA
50 °C/W
Operating and Storage Temperature Range
T
J
,
T
STG
-55 to +150
°C
Notes:
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our webs3. Device mounted on FR-4 PCB, with minimum recommended pad layout.
4. Repetitive rating, pulse width limited by junction temperature.
SO-8
Top View
Top View
D
1
S
1
G
1
D
2
S
2
G
2
N-Channel MOSFET
P-Channel MOSFET
S2
D1
S1
D2
G1
G2
D2
D1
