Diodes DMC3028LSDX User Manual
Dmc3028lsdx, Product summary, Description

DMC3028LSDX
Document number: DS36210 Rev. 3 - 2
1 of 9
June 2013
© Diodes Incorporated
DMC3028LSDX
ADVAN
C
E
I
N
F
O
R
MA
T
IO
N
ADVAN
C
E
D
I
N
F
O
RM
AT
IO
N
COMPLEMENTARY PAIR ENHANCEMENT MODE MOSFET
Product Summary
Device
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
Q1
30V
27m
Ω @ V
GS
= 10V
7.2A
35m
Ω @ V
GS
= 4.5V
6.0A
Q2
-30V
25m
Ω @ V
GS
= -10V
-7.6A
41m
Ω @ V
GS
= -4.5V
-6.2A
Description
This new generation MOSFET has been designed to minimize the on-
state resistance (R
DS(ON)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
Applications
•
DC-DC Converters
•
Power Management Functions
•
Backlighting
Features and Benefits
•
Low Input Capacitance
•
Low On-Resistance
•
Fast Switching Speed
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
Case: SO-8
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: See Diagram
•
Terminals: Finish – Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Weight: 0.074 grams (approximate)
Ordering Information
(Note 4)
Part Number
Case
Packaging
DMC3028LSDX-13
SO-8
2,500/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. Se
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Top View
Top View
Pin Configuration
Equivalent Circuit
D1
S1
G1
S2
G2
D1
D2
D2
Top View
Logo
Part no
.
Year: “11” = 2011
1
4
8
5
3028SDX
YY
WW
Xth week: 01 ~ 53
e3
