Electrical Characteristics – Q2
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 8)
Drain-Source Breakdown Voltage
BV
DSS
-30
V
V
GS
= 0V, I
D
= -250µA
Zero Gate Voltage Drain Current
I
DSS
-1
µ
A
V
DS
= -24V, V
GS
= 0V
Gate-Source Leakage
I
GSS
±100
nA
V
GS
=
±20V, V
DS
= 0V
ON CHARACTERISTICS (Note 8)
Gate Threshold Voltage
V
GS(th)
-1
-3
V
V
DS
= V
GS
, I
D
= -250µA
Static Drain-Source On-Resistance
R
DS (ON)
21
25
m
Ω
V
GS
= -10V, I
D
= -6A
29
41
V
GS
= -4.5V, I
D
= -5A
Diode Forward Voltage
V
SD
-0.7
-1.2
V
V
GS
= 0V, I
S
= -1.3A
DYNAMIC CHARACTERISTICS (Note 9)
Input Capacitance
C
iss
1241
pF
V
DS
= -15V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
146
Reverse Transfer Capacitance
C
rss
110
Gate Resistance
R
G
14.8
Ω
V
DS
= 0V, V
GS
= 0V, f = 1.0MHz
Total Gate Charge (V
GS
= -4.5V)
Q
g
10.9
nC
V
DS
= -15V, I
D
= -7A
Total Gate Charge (V
GS
= -10V)
Q
g
22
Gate-Source Charge
Q
gs
3.5
Gate-Drain Charge
Q
gd
4.7
Turn-On Delay Time
t
D(on)
9.7
nS
V
GS
= -10V, V
DD
= -15V, R
GEN
= 6
Ω,
I
D
= -7A
Turn-On Rise Time
t
r
17.1
Turn-Off Delay Time
t
D(off)
60.5
Turn-Off Fall Time
t
f
40.4
Notes:
8. Short duration pulse test used to minimize self-heating effect.
9. Guaranteed by design. Not subject to product testing.
