DMP4050SSD
Maximum Ratings
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Drain-Source Voltage V DSS
-40 V
Gate-Source Voltage (Note 5) V
GS
20 V
Continuous Drain Current V
GS
= 10V
(Notes 9 & 11)
I
D
-5.2
A T
A
= +70°C (Notes 7 & 9) -4.2
(Notes 6 & 9) -4.0
Pulsed Drain Current V
GS
= 10V (Notes 8 & 9) I
DM
-20.0 A
Continuous Source Current (Body Diode) (Notes 7 & 9) I S
-3.2 A
Pulsed Source Current (Body Diode) (Notes 8 & 9) I
SM
-20.0 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power dissipation
Linear derating factor
(Notes 6 & 9)
P D
1.25
10.0
W
mW/°C
(Notes 6 & 10)
1.8
14.3
(Notes 7 & 9)
2.14
17.2
Thermal Resistance, Junction to Ambient
(Notes 6 & 9)
R θJA
100
°C/W
(Notes 6 & 10) 70
(Notes 7 & 9) 58
Thermal Resistance, Junction to Lead (Notes 9 & 11) R JL 53
Operating and storage temperature range T
J
, T
STG
-55 to +150 °C
Notes: 5. AEC-Q101 V
GS
maximum is 16V.
6. For a device surface mounted on 25mm x 25mm x 1.6mm FR4 PCB with high coverage of single sided 1oz copper, in still air conditions; the device is
measured when operating in a steady-state condition.
7. Same as note (3), except the device is measured at t
 10 sec.
8. Same as note (3), except the device is pulsed with D = 0.02 and pulse width 300µs. The pulse current is limited by the maximum junction temperature.
9. For a dual device with one active die.
10. For a device with two active die running at equal power.
11. Thermal resistance from junction to solder-point (at the end of the drain lead).
