Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SOT23
Dim Min Max Typ
A
0.37 0.51 0.40
B
1.20 1.40 1.30
C
2.30 2.50 2.40
D
0.89 1.03 0.915
F
0.45 0.60 0.535
G
1.78 2.05 1.83
H
2.80 3.00 2.90
J
0.013 0.10 0.05
K
0.890 1.00 0.975
K1
0.903 1.10 1.025
L
0.45 0.61 0.55
L1
0.25 0.55 0.40
M
0.085 0.150 0.110
8°
All Dimensions in mm
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
0.001
0.01
0.1
0.00001
0.0001
0.001
0.01
0.1
1
10
100
1000
t1, PULSE DURATION TIMES (sec)
Fig. 13 Transient Thermal Resistance
R (t)=r(t) * R
JA
JA
R =54°C/W
Duty Cycle, D=t1/ t2
JA
r(
t)
, T
R
ANSI
E
N
T
T
H
ERM
A
L
RES
IS
TANCE
r(t) @ D=0.9
r(t) @ D=0.7
r(t) @ D=0.5
r(t) @ D=0.3
r(t) @ D=0.1
r(t) @ D=0.05
r(t) @ D=0.02
r(t) @ D=0.01
r(t) @ D=0.005
r(t) @ D=Single Pulse
1
J
K 1
K
L 1
G A U G E P L A N E
0 . 2 5
H
L
M
A l l 7 °
A
C
B
D
G
F
a
Dimensions Value (in mm)
Z
2.9
X
0.8
Y
0.9
C
2.0
E
1.35
X
E
Y
C
Z
