DMP22D4UFA

Document number: DS35766 Rev. 2 - 2

1 of 6

www.diodes.com

May 2012

© Diodes Incorporated

DMP22D4UFA

NEW PROD

UC

T


20V P-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

V

(BR)DSS

R

DS(ON)

max

I

D

max

T

A

= 25°C

-20V

1.9

Ω @ V

GS

= -4.5V

-330mA

2.4

Ω @ V

GS

= -2.5V

-300mA

3.4

Ω @ V

GS

= -1.8V

-250mA

5

Ω @ V

GS

= -1.5V

-200mA

Description and Applications

This MOSFET has been designed to minimize the on-state resistance
(R

DS(on)

) and yet maintain superior switching performance, making it

ideal for high efficiency power management applications.

General Purpose Interfacing Switch

Power Management Functions

• Analog

Switch

Features and Benefits

Low Package Profile, 0.4mm Maximum Package height

• 0.48mm

2

package footprint, 16 times smaller than SOT23

• Low

On-Resistance

Very low Gate Threshold Voltage, 1.0V max

• ESD

Protected

Gate

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 standards for High Reliability

Mechanical Data

• Case:

X2-DFN0806-3

Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish – NiPdAu over Copper leadframe.
Solderable per MIL-STD-202, Method 208

Weight: 0.001 grams (approximate)


















Ordering Information

(Note 4)

Part Number

Case

Packaging

DMP22D4UFA-7B

DFN0806H4-3

10K/Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.



3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.



Marking Information














Bottom View

Equivalent Circuit

PW = Product Type Marking Code

DMP22D4UFA-7B

Top View

Bar Denotes Gate

and Source Side

Top View

Package Pin Configuration

Source

Gate
Protection
Diode

Gate

Drain

D

S

G

PW

ESD PROTECTED
