DMP2004VK

Document number: DS30916 Rev. 6 - 2

2 of 5

www.diodes.com

August 2012

© Diodes Incorporated

DMP2004VK





Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Value

Units

Drain-Source Voltage

V

DSS

-20 V

Gate-Source Voltage

V

GSS

±8 V

Continuous Drain Current (Note 5) V

GS

= -4.5V

Steady

State

T

A

= +25

°C

T

A

= +70

°C

I

D

-0.53
-0.44

A

Continuous Drain Current (Note 5) V

GS

= -2.5V

Steady

State

T

A

= +25

°C

T

A

= +70

°C

I

D

-0.44
-0.35

A

Pulsed Drain Current (Note 6)

I

DM

-1.8 A



Thermal Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Value

Units

Total Power Dissipation (Note 5)

P

D

400 mW

Thermal Resistance, Junction to Ambient

R

θJA

312 °C/W

Operating and Storage Temperature Range

T

J,

T

STG

-65 to +150

°C



Electrical Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage

BV

DSS

-20

V

V

GS

= 0V, I

D

= -250

μA

Zero Gate Voltage Drain Current

I

DSS

-1.0

μA

V

DS

= -20V, V

GS

= 0V

Gate-Source Leakage

I

GSS

±1.0

μA

V

GS

=

±4.5V, V

DS

= 0V

ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage

V

GS(th)

-0.5

-1.0 V

V

DS

= V

GS

, I

D

= -250

μA

Static Drain-Source On-Resistance

R

DS (ON)

0.7
1.1

1.7

0.9
1.4
2.0

Ω

V

GS

= -4.5V, I

D

= -430mA

V

GS

= -2.5V, I

D

= -300mA

V

GS

= -1.8V, I

D

= -150mA

Forward Transfer Admittance

|Y

fs

|

200

mS

V

DS

= -10V, I

D

= -0.2A

Diode Forward Voltage (Note 5)

V

SD

-0.5

-1.2 V

V

GS

= 0V, I

S

= 115mA

DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance

C

iss

175 pF

V

DS

= -16V, V

GS

= 0V

f = 1.0MHz

Output Capacitance

C

oss

30 pF

Reverse Transfer Capacitance

C

rss

20 pF

Notes:

5. Device mounted on FR-4 PCB, with minimum recommended pad layout.
6. Device mounted on minimum recommended pad layout test board, 10

μs pulse duty cycle = 1%.

7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to product testing.
