12V P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
-12V
15.3m
Ω @ V
GS
= -4.5V
-9.5A
19
mΩ @ V
GS
= -2.5V
-8.5A
26.5m
Ω @ V
GS
= -1.8V
-7.2A
32m
Ω @ V
GS
= -1.5V
-6.6A
Description
This MOSFET has been designed specifically for use in battery
management applications.
Features
0.6mm profile
– ideal for low profile applications
PCB footprint of 4mm
2
Low Gate Threshold Voltage
Fast Switching Speed
ESD Protected Gate
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: U-DFN2020-6
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish
– NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208
Weight: 0.0065 grams (approximate)
Ordering Information
(Note 4)
Part Number
Marking
Reel Size (inches)
Quantity per Reel
DMP1022UFDF-7
PU
7
3,000
DMP1022UFDF-13
PU
13
10,000
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See
more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-
free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2011
2012
2013
2014
2015
2016
2017
Code
Y
Z
A
B
C
D
E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code
1
2
3
4
5
6
7
8
9
O
N
D
Pin Out
ESD PROTECTED
Internal Schematic
PU = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: A = 2013)
M = Month (ex: 9 = September)
U-DFN2020-6
Bottom View
PU
Y
M
Bottom View
Top View
D
S
G
Gate Protection
Diode
e4
