background image

DMT6010LFG

Document number: DS36620 Rev. 2 - 2

1 of 6

www.diodes.com

March 2014

© Diodes Incorporated

DMT6010LFG

NEW PROD

UC

T

ADVAN

CE I

N

F

O

RM

ATI

O

N


N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

V

(BR)DSS

R

DS(ON)

max

I

D

max

T

C

= +25°C

60V

7.5mΩ @ V

GS

= 10V

30A

11.5mΩ @ V

GS

= 4.5V

25A


Description

This MOSFET has been designed to minimize the on-state resistance
(R

DS(on)

) and yet maintain superior switching performance, making it

ideal for high efficiency power management applications.

Applications

 Synchronous

Rectifier

 Backlighting

Power Management Functions

 DC-DC

Converters

Features and Benefits

 Low

R

DS(ON)

– ensures on state losses are minimized

 Excellent

Q

gd x

R

DS (ON

)

Product (FOM)

Advanced Technology for DC/DC converts

Small form factor thermally efficient package enables higher
density end products

Occupies just 33% of the board area occupied by SO-8 enabling
smaller end product

100% UIS (Avalanche) rated

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

 Case:

POWERDI

®

3333-8

Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

 Terminal

Connections

Indicator: See diagram

 Terminals:

Finish

 Matte Tin annealed over Copper leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.008 grams (approximate)

















Ordering Information

(Note 4)

Part Number

Case

Packaging

DMT6010LFG-7

POWERDI

®

3333-8

2000/Tape & Reel

DMT6010LFG-13

POWERDI

®

3333-8

3000/Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.


Marking Information








Top View

Equivalent Circuit

SG6 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 13 = 2013)
WW = Week code (01 ~ 53)

Bottom View

S

S

S

G

D

D

D

D

Pin 1

D

S

G
