DMN25D0UFA
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Drain-Source Voltage V
DSS
25
V
Gate-Source Voltage V
GSS
8
Continuous Drain Current, V
GS
= 4.5V
(Note 6)
I
D
0.32
A
T
A
= +70°C (Note 6) 0.25
(Note 5) I
D
0.24 A
Pulsed Drain Current (Note 7) I
DM
1.2 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 6)
P
D
0.63
W
(Note 5) 0.28
Thermal Resistance, Junction to Ambient
(Note 6)
R
θJA
201
°C/W
(Note 5) 338
Operating and Storage Temperature Range T
J , T
STG
-55 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
25 — — V V
GS
= 0V, I
D
= 250μA
Zero Gate Voltage Drain Current I
DSS
— — 1 µA V
DS
= 20V, V
GS
= 0V
Gate-Source Leakage I
GSS
— — 100 nA V
GS
= 8V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
0.6 — 1.2 V V
DS
= V
GS
, I
D
= 250μA
Static Drain-Source On-Resistance R
DS(on)
—
— —
— 4
Ω
V
GS
= 4.5V, I
D
= 0.4A
5 V
GS
= 2.7V, I
D
= 0.2A
Forward Transfer Admittance |Y
fs
| — 1 - S V
DS
= 5V, I
D
= 0.4A
Diode Forward Voltage V
SD
— 0.76 1.2 V V
GS
= 0V, I
S
= 0.29A
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
— 27.9 — pF
V
DS
= 10V, V
GS
= 0V,
f = 1MHz
Output Capacitance C
oss
— 6.1 — pF
Reverse Transfer Capacitance C
rss
— 2 — pF
Gate Resistance R
g
— 26.4 — Ω V
DS
= 0V, V
GS
= 0V, f = 1MHz
Total Gate Charge Q
g
— 0.36 — nC
V
DS
= 5V, V
GS
= 4.5V,
I
D
= 0.2A
Gate-Source Charge Q
gs
— 0.06 — nC
Gate-Drain Charge Q
gd
— 0.04 — nC
Turn-On Delay Time t
D(on)
— 2.9 — ns
V
DS
= 6V, V
GS
= 4.5V,
I
D
= 0.5A, R
G
= 50Ω
Turn-On Rise Time t
r
— 1.8 — ns
Turn-Off Delay Time t
D(off)
— 6.6 — ns
Turn-Off Fall Time t
f
— 2.3 — ns
Notes: 5. Device mounted on FR-4 PC board, with minimum recommended pad layout, single sided.
6. Device mounted on 1” x 1” FR-4 PCB with high coverage 2oz. Copper, single sided.
7 .Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to production testing.
