DMN2016LHAB

Document number: DS36133 Rev. 4 - 2

1 of 6

www.diodes.com

March 2013

© Diodes Incorporated

DMN2016LHAB

ADVAN

CE I

N

F

O

RM

ATI

O

N

NEW PROD

UC

T


DUAL N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

V

(BR)DSS

R

DS(on)max

I

D

T

A

= +25°C

20V

15.5m

 @ V

GS

= 4.5V

7.5A

16.5m

 @ V

GS

= 4.0V

7.3A

19m

 @ V

GS

= 3.1V

6.9A

20m

 @ V

GS

= 2.5V

6.7A

30m

 @ V

GS

= 1.8V

5.4A

Description

This new generation MOSFET has been designed to minimize the on-
state resistance (R

DS(ON)

) and yet maintain superior switching

performance, making it ideal for high efficiency power management
applications.

Applications

Power Management Functions

 Battery

Pack

 Load

Switch

Features

 Low

On-Resistance

Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

ESD Protected Gate

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)


Mechanical Data

 Case:

U-DFN2030-6

Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish – NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208

Weight: 0.012 grams (approximate)






















Ordering Information

(Note 4)

Part Number

Case

Packaging

DMN2016LHAB-7

U-DFN2030-6

3000 / Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http”//www.diodes.com/products/packages.html.


Marking Information









ESD PROTECTED TO 2kV

26W = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 12 for 2012)
WW = Week code (01 to 53)

Top View

Equivalent Circuit

S2 S2 G2

S1 S1 G1

Bottom Drain Contact

26W

YYW

W

S1

S1

G2

G1

S2

S2

D1/D2

Bottom View

U-DFN2030-6

e4
