FMMT415-FMMT417
Datasheet Number: DS33084 Rev. 5 - 2
2 of 7
www.diodes.com
February 2014
© Diodes Incorporated
FMMT415
FMMT417
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol FMMT415 FMMT417 Unit
Collector-Base Voltage V
CBO
260 320 V
Collector-Emitter Voltage V
CES
260 320 V
Collector-Emitter Voltage V
CEO
100 100 V
Emitter-Base Voltage V
EBO
6 V
Continuous Collector Current I
C
500 mA
Peak Collector Current (Pulse Width = 20ns) I
CM
60 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
500 mW
Thermal Resistance, Junction to Ambient (Note 5) R
θJA
250 °C/W
Thermal Resistance, Junction to Lead (Note 6) R
θJL
197 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 7)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with the collector lead on 15mm x 15mm 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in a steady-state.
6. Thermal resistance from junction to solder-point (at the end of the collector lead).
7. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
