FCX558
Da
tasheet Number: DS33059 Rev. 4 - 2
3 of 6
November 2012
© Diodes Incorporated
FCX558
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ.
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-400 - -
V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 7)
BV
CEO
-400 - -
V
I
C
= -1mA
Emitter-Base Breakdown Voltage
BV
EBO
-7 - - V
I
E
= -100µA
Collector Cutoff Current
I
CBO
- - -100 nA
V
CB
= -320V
Emitter Cutoff Current
I
EBO
- - -100 nA
V
EB
= -5V
Emitter Cutoff Current
I
CES
- - -100 nA
V
CES
= -320V
DC current transfer Static ratio (Note 7)
h
FE
100
100
15
-
-
-
-
300
-
-
I
C
= -1mA, V
CE
= -10V
I
C
= -50mA, V
CE
= -10V
I
C
= -100mA, V
CE
= -10V
Collector-Emitter Saturation Voltage (Note 7)
V
CE(sat)
-
-
-
-
-0.2
-0.5
V
I
C
= -20mA, I
B
= -2mA
I
C
= -50mA, I
B
= -6mA
Base-Emitter Saturation Voltage (Note 7)
V
BE(sat)
- -
-0.9 V
I
C
= -50mA, I
B
= -5mA
Base-Emitter Turn-on Voltage (Note 7)
V
BE(on)
- -
-0.9 V
I
C
= -50mA, V
CE
= -10V
Transitional Frequency
f
T
50 - - MHz
I
E
= -10mA, V
CE
= -20V
f = 20MHz
Output capacitance
C
obo
- - 5 pF
V
CB
= -20V, f = 1MHz,
Switching times
t
on
-
95
- nS
I
C
= -50mA, V
C
= -100V
I
B1
= -5mA, I
B2
= -10mA
t
off
1600
Notes:
7. Measured under pulsed conditions. Pulse width
≤ 300μs. Duty cycle ≤ 2%.
